Conky: Απορίες/Χρήσεις/Εφαρμογές

[sotos21]

Και τέλος αν γίνετε να αντιμετωπίσω αυτό που κάνει το conky στις γρήγορες εναλλαγές τον αριθμόν.
Δηλαδή πχ φαίνεται σαν να πατα το ένα νούμερο πάνω από το άλλο όταν αλλάζει.

Δείξε όλο το conkyrc

Αν είναι εύκολο να φτιάξουμε της τέσσερις γραμμές για τους πυρήνες του επεξεργαστή.

Δηλαδή θέλεις να βλέπεις τις παρακάτω θερμοκρασίες;

Κώδικας: Επιλογή όλων

Core 0: +42.0°C
Core 1: +43.0°C
Core 2: +44.0°C
Core 3: +42.0°C

[nikpoth]

Κώδικας: Επιλογή όλων

####
## Use XFT? Required to Force UTF8 (see below)
#
use_xft yes
xftfont DroidSans:size=8.75
xftalpha 0.1

####
## Force UTF8? Requires XFT (see above)
## Displays degree symbol, instead of °, etc.
#
override_utf8_locale yes

####
## This buffer is used for single lines, text, output from $exec, and other variables.
## Increasing the 'text_buffer_size' (too high) will drastically reduce Conky's performance.
## Decreasing the buffer size (too low) will truncate content and cause strange display output.
## Standard text buffer size is 256 bytes (cannot be less). Adjust YOUR buffer wisely!
## Tips n' Tricks from dk75:"You don't need to create a 12KiB buffer for every Conky config line."
#
text_buffer_size 4352

####
## Maximum number of special things, e.g. fonts, offsets, aligns, etc. (default is 512)
## Tips n' Tricks from: sparker256 (Thanks, Bill!)
#
max_specials 700

####
## Daemonize Conky, aka 'fork to background'.
#
background yes

####
## Update interval in seconds.
#
update_interval 2.0

####
## The number of times Conky will update before quitting.
## Zero makes Conky run forever.
#
total_run_times 0

####
## Create 'own_window' type. Makes Conky behave like other panels.
#
own_window yes
own_window_transparent yes
own_window_type normal
own_window_hints undecorated,below,sticky,skip_taskbar,skip_pager
####
## Some distros require the following lines for true transparency.
## BOTH of these lines need to be Commented/Uncommented in tandem.
#
own_window_argb_visual yes
own_window_argb_value 255

####
## Force images to redraw when they change.
#
imlib_cache_size 1

####
## Use double buffering? Reduces flicker.
#
double_buffer yes

own_window_transparent yes

####
## Draw shades?
#
draw_shades no
default_shade_color 330

####
## Draw outlines?
#
draw_outline no

####
## Draw borders around text?
#
draw_borders no

####
## Draw borders around graphs?
#
draw_graph_borders no

####
## Print text to stdout?
## Print text in console?
#
out_to_ncurses no
out_to_console no

####
## Text alignment.
#
alignment top_right

####
## Minimum size of the text area.
## Syntax: minimum_size [width] [height]
#
#minimum_size 245 1394
minimum_size 445 1894
maximum_width 1200
####added by me
## Maximum size of user text buffer, i.e. layout below TEXT line in config file (default is 16384 bytes)
max_user_text 114688

####
## Maximum width of the text area.
## Syntax: maximum_width [width]
#
maximum_width 290

####
## Gap between text and screen borders.
#
gap_x 6 # Left/Right
gap_y 32 # Top/Bottom

####
## Shorten MiB/GiB to M/G in stats.
#
short_units yes

####
## Pad % symbol spacing after numbers.
#
pad_percents 0

####
## Pad spacing between text and borders.
#
border_inner_margin 2

####
## Limit the length of names in "Top Processes".
#
top_name_width 10

####
## Subtract file system -/+buffers/cache from used memory?
## Set to yes, to produce meaningful physical memory stats.
#
no_buffers yes

####
## Set to yes, if you want all text to be in UPPERCASE.
#
uppercase no

####
## Number of cpu samples to average.
## Set to 1 to disable averaging.
#
cpu_avg_samples 4

####
## Number of net samples to average.
## Set to 1 to disable averaging.
#
net_avg_samples 2

####
## Add spaces to keep things from moving around?
## Only affects certain objects.
#
use_spacer right

####
## My colors (suit yourself)
#
color0 White #FFFFFF
color1 Ivory #FFFFF0
color2 Ivory2 #EEEEE0
color3 Ivory3 #CDCDC1
color4 Tan1 #FFA54F
color5 Tan2 #EE9A49
color6 Gray #7E7E7E
color7 AntiqueWhite4 #8B8378
color8 DimGray #696969
color9 OrangeRed #FF4500


#####
## Load Lua for shading (optional)
## Set the path to your script here.
#
lua_load ~/.conky/draw_bg.lua
lua_draw_hook_pre draw_bg

####
## Load Lua for bargraphs (required)
## Set the path to your script here.
#
lua_load ~/.conky/bargraph_small.lua
#lua_load ~/.conky/bargraph_testing.lua
lua_draw_hook_post main_bars

####
## Define the locations of Conkywx files (required)
## Set the path to your .confs and templates here.
#
template0 "/usr/share/conkywx/conkywx.sh"
template2 "/home/nikos/.config/conkywx/vindsl-metric-conkywx.conf"
template6 "/home/nikos/.config/conkywx/wx-wu-vindsl-metric-weather-graphic-template.sh"

TEXT
##################################
## LOGO ##
##################################
## Uncomment for soft-coded ID (dynamic)
${voffset -33}${font OpenLogos:size=100}${color2}v${font}${voffset -76}${goto 178}${font ubuntu-title:bold:size=19}${color9}14.04${font ubuntu-title:bold:size=12}${color9}. LTS${offset 8}${font}

####
## Additional ID (branch version, code name, release date, etc.)
####
##################################
## SYSTEM ##
##################################
${voffset 7}${font DroidSans:bold:size=8}${color9}SYSTEM${offset 8}${color9}${voffset -2}${hr 1}${font}
# ${voffset 4}${font OpenLogos:size=10}${color9}u${voffset -4}${font DroidSans:size=8.6}${color0}${offset 5}${pre_exec lsb_release -sd || cat /etc/*release}${font}
${voffset 2}${offset -2}${font OpenLogos:size=12}${color9}Z${voffset -4}${font DroidSans:size=8.6}${color0}${offset 3}${sysname}${offset 3}${kernel}${alignr}${font DroidSans:size=8.3}${machine}${font}
${voffset 2}${font StyleBats:size=10}${color9}d${voffset -2}${font DroidSans:size=8.6}${color0}${offset 5}${pre_exec lspci | grep VGA | sed -e 's/.*\[\([^]]*\)\].*/\1/g'}${alignr}${pre_exec fglrxinfo | grep version | awk '{print $NF}'}${font}
${voffset 2}${font StyleBats:size=10}${color9}A${voffset -1}${font DroidSans:size=8.6}${color0}${offset 5}Intel${offset 3}i5 2500K${offset 3}Sandy${offset 3}Bridge${alignr 1}${font DroidSans:size=8.3}${freq_g cpu0}${offset 1}GHz${font}
${voffset 2}${font StyleBats:size=10}${color9}q${voffset -1}${font DroidSans:size=8.6}${color0}${offset 5}System${offset 3}Uptime${alignr}${font DroidSans:size=8.3}${uptime_short}${font}
##################################
## PROCESSORS ##
##################################
${voffset 4}${font DroidSans:bold:size=8}${color9}PROCESSORS${offset 8}${color9}${voffset -2}${hr 1}${font}
${voffset 4}${font StyleBats:size=9.9}${color9}k${voffset -2}${font DroidSansFallback:size=8.39}${color0}${offset 2}CPU1${offset 5}${font DroidSans:size=8.3}${alignr}${cpu cpu1}%${font}
${voffset 2}${font StyleBats:size=9.9}${color9}k${voffset -2}${font DroidSansFallback:size=8.39}${color0}${offset 2}CPU2${offset 5}${font DroidSans:size=8.3}${alignr}${cpu cpu2}%${font}
${voffset 2}${font StyleBats:size=9.9}${color9}k${voffset -2}${font DroidSansFallback:size=8.39}${color0}${offset 2}CPU3${offset 5}${font DroidSans:size=8.3}${alignr}${cpu cpu3}%${font}
${voffset 2}${font StyleBats:size=9.9}${color9}k${voffset -2}${font DroidSansFallback:size=8.39}${color0}${offset 2}CPU4${offset 5}${font DroidSans:size=8.3}${alignr}${cpu cpu4}%${font}
##################################
## MEMORY ##
##################################
${voffset 4}${font DroidSans:bold:size=8}${color9}MEMORY${offset 8}${color9}${voffset -2}${hr 1}${font}
${voffset 4}${font StyleBats:size=10}${color9}l${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 3}RAM${goto 97}${font DroidSans:size=8.3}${mem}${goto 133}/${offset 5}${memmax}${alignr}${memperc}%${font}
##################################
## HDD ##
##################################
${voffset 15}${font DroidSans:bold:size=8}${color9}HARD DISK DRIVES${offset 8}${color9}${voffset -2}${hr 1}${font}
${voffset 6}${font StyleBats:size=9.9}${color9}x${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 4}ROOT${goto 95}${font DroidSans:size=8.3}${fs_used /}${goto 133}/${offset 5}${fs_size /}${alignr}${fs_free_perc /}%${font}
${voffset 15}${font StyleBats:size=9.9}${color9}x${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 4}HOME${goto 95}${font DroidSans:size=8.3}${fs_used /home}${goto 133}/${offset 5}${fs_size /home}${alignr}${fs_free_perc /home}%${font}
${voffset 15}${font StyleBats:size=9.9}${color9}x${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 4}SWAP${goto 95}${font DroidSans:size=8.3}${swap}${goto 133}/${offset 5}${swapmax}${alignr}${swapperc}%${font}
${voffset 15}${font StyleBats:size=9.9}${color9}x${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 4}Torrent ${goto 95}${font DroidSans:size=8.3}${fs_used /media/Torrent}${goto 133}/${offset 5}${fs_size /media/Torrent}${alignr}${fs_free_perc /media/Torrent}%${font}
${voffset 15}${font StyleBats:size=9.9}${color9}x${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 4}Multimedia ${goto 95}${font DroidSans:size=8.3}${fs_used /media/Programs-Multimedia}${goto 133}/${offset 5}${fs_size /media/Programs-Multimedia}${alignr}${fs_free_perc /media/Programs-Multimedia}%${font}
##################################
## TOP PROCESSES ##
##################################
${voffset 15}${font DroidSans:bold:size=8}${color9}TOP PROCESSES${offset 8}${color9}${voffset -2}${hr 1}${font}
${voffset 4}${font StyleBats:size=10}${color9}h${voffset -1}${font DroidSans:size=8.65}${color0}${offset 5}${top_mem name 1}${goto 120}${font DroidSans:size=8.3}${top_mem mem_res 1}${alignr}${top_mem mem 1}%${font}
${voffset 1}${font StyleBats:size=10}${color9}h${voffset -1}${font DroidSans:size=8.65}${color0}${offset 5}${top_mem name 2}${goto 120}${font DroidSans:size=8.3}${top_mem mem_res 2}${alignr}${top_mem mem 2}%${font}
${voffset 1}${font StyleBats:size=10}${color9}h${voffset -1}${font DroidSans:size=8.65}${color0}${offset 5}${top_mem name 3}${goto 120}${font DroidSans:size=8.3}${top_mem mem_res 3}${alignr}${top_mem mem 3}%${font}
${voffset 1}${font StyleBats:size=10}${color9}h${voffset -1}${font DroidSans:size=8.65}${color0}${offset 5}${top_mem name 4}${goto 120}${font DroidSans:size=8.3}${top_mem mem_res 4}${alignr}${top_mem mem 4}%${font}
##################################
## NETWORK ##
##################################
${voffset 4}${font DroidSans:bold:size=8}${color9}NETWORK${offset 8}${color9}${voffset -2}${hr 1}${font}
${voffset 4}${font PizzaDudeBullets:size=9.5}${color9}T${font DroidSans:size=8.65}${color0}${offset 5}Download${goto 120}${font DroidSans:size=8.3}${totaldown eth0}${alignr}${font DroidSans:size=8.3}${downspeed eth0}${font}
${voffset 0}${font PizzaDudeBullets:size=9.5}${color9}N${font DroidSans:size=8.65}${color0}${offset 5}Upload${goto 120}${font DroidSans:size=8.3}${totalup eth0}${alignr}${font DroidSans:size=8.3}${upspeed eth0}${font}
${voffset 4}${font StyleBats:size=9.5}${color9}a${font DroidSans:size=8.65}${color0}${offset 5}Private${offset 3}IP${goto 123}${font DroidSansFallback:size=8.3}LAN${alignr -9}${font DroidSans:size=8.3}${addr eth0}${font}
${voffset 0}${font StyleBats:size=9.5}${color9}a${font DroidSans:size=8.65}${color0}${offset 5}Public${offset 7}IP${goto 121}${font DroidSansFallback:size=8.3}WAN${alignr -9}${font DroidSans:size=8.3}${execi 1800 wget -q -O - checkip.dyndns.org | sed -e 's/[^[:digit:]\|.]//g'}${font}
##################################
## TEMPERATURES ##
##################################
${voffset 5}${font DroidSans:bold:size=8}${color9}CPU/GPU TEMPERATURES${offset 8}${color9}${voffset -2}${hr 1}${font}
${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 1: $alignr${execi 10 sensors | grep ^temp2 | awk '{print $2}' | cut -c2-9}
${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 2: $alignr${execi 10 sensors | grep ^temp2 | awk '{print $2}' | cut -c2-9}
${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 3: $alignr${execi 10 sensors | grep ^temp2 | awk '{print $2}' | cut -c2-9}
${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 4: $alignr${execi 10 sensors | grep ^temp2 | awk '{print $2}' | cut -c2-9}
${voffset 4}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}M/B GIGABYTE Temp: $alignr${execi 10 sensors | grep ^temp3 | awk '{print $2}' | cut -c2-9}
${voffset 4}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}GPU Temperature:$alignr${execi 3 sensors radeon-pci-0100 | grep "temp1" | cut -c16-17 ;}°C
${voffset 4}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}Torrent Temp: $alignr${hddtemp}°C

Ναι Σωτήρη,αυτές τις τέσσερις θέλω

[sotos21]

Για πες τι γίνεται αν βάλεις # μπροστά από το own_window_argb_visual yes
να γίνει δηλαδή έτσι

Κώδικας: Επιλογή όλων

#own_window_argb_visual yes

[nikpoth]

Αποθήκευσα,μαύρισε το conky,μετά έκλεισε από μονο του και το άνοιξα με τερματικό.
Όμως δουλεύει χωρίς το πρόβλημα τώρα.

[sotos21]

Επίσης κοίτα αν δώσεις την εντολή

Κώδικας: Επιλογή όλων

sensors coretemp-isa-0000 | grep "Core 3"

Παίρνεις θερμοκρασία από τον τρίτο πυρήνα;

[nikpoth]

όχι, αλλα μήπως δεν την έδωσα σωστά?

Κώδικας: Επιλογή όλων

CPU Core Temp 3: $alignr${execi 10 sensors coretemp-isa-0000 | grep "Core 3" | awk '{print $2}' | cut -c2-9}

τα έχω παίξει λίγο με το ψάξιμο,sorry.

Κώδικας: Επιλογή όλων

nikos@nikos-Z68X-UD4-B3:~$ sensors coretemp-isa-0000 | grep "Core 3"
Core 3: +35.0°C (high = +80.0°C, crit = +98.0°C)
nikos@nikos-Z68X-UD4-B3:~$


[sotos21]

Δοκίμασε να κάνεις τις γραμμές του conkyrc έτσι

Κώδικας: Επιλογή όλων

${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 1: $alignr${execi 3 sensors coretemp-isa-0000 | grep "Core 0" | cut -c18-19 ;}°C
${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 2: $alignr${execi 3 sensors coretemp-isa-0000 | grep "Core 1" | cut -c18-19 ;}°C
${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 3: $alignr${execi 3 sensors coretemp-isa-0000 | grep "Core 2" | cut -c18-19 ;}°C
${voffset 5}${font StyleBats:size=9.5}${color9}k${voffset -2}${font DroidSansFallback:size=8.3}${color0}${offset 2}CPU Core Temp 4: $alignr${execi 3 sensors coretemp-isa-0000 | grep "Core 3" | cut -c18-19 ;}°C

Το μαύρισμα υπάρχει ή είσαι εντάξει;

[nikpoth]

Όλα δουλεύουν κομπλέ τώρα!
Σωτήρη σου έβγαλα τα ματια ρε φιλε.
Σε ευχαριστώ πολύ.
Παιδεύομαι πολλές ώρες με το συγκεκριμένο και με βοηθησε πολύ ο spirosmeg στην αρχή.
Με έκανες μάγκα τώρα,παίζει super! ούτε διπλότυπα νούμερα στις αλλαγές ούτε μαύρισμα.
Να είσαι καλά.

thanks και για τις θερμοκρασιες στην καρτούλα μου.

[the_eye]

Για δείτε και αυτό το GUI εργαλείο για ρύθμιση του conky

http://www.teejeetech.in/p/conky-manager.html

[dgtfeargr]

Μετά από καθαρή εγκατάσταση Ubuntu 14.04 και εγκατάσταση του Conky, δεν λειτουργεί ο αισθητήρας θερμοκρασίας του σκληρού δίσκου ούτε στο Conky , ούτε στο Psensor. Έχω εγκαταστήσει lm-sensors, hddtemp, hddtemp host και το indicator-sensors_0.2-1_amd64.deb
